Mainstream material grading and parameter comparison
- Cr12MoV HRC 58~62 Low-carbon iron wire, galvanized iron wire High cost performance, good toughness, not prone to chipping Small and medium-sized conventional mass production, general nail factories
- SKD11 HRC 60~63 Medium carbon steel, tempered steel wire Wear-resistant and fatigue-resistant, stable continuous high-speed operation Medium-sized large-scale assembly line
- M2 high-speed steel, HRC 62~65, stainless steel wire, high-hardness carbon steel, high temperature resistance, high-speed thread rolling without burning teeth, production of stainless steel nails, high-strength special nails
- Cemented carbide (tungsten steel) HRA 88~92 Hard steel wire, ultra-high daily production conditions Lifespan is 5~8 times that of mold steel, wear-resistant tip Large factories produce over 10 tons per day
advantages
- 1. High molding accuracy
The coaxiality of the inner and outer circles is ≤0.005mm, the thread profile angle tolerance is ±0.01°, and the pass rate of finished thread inspection using a go/no-go gauge is ≥99.5%;
Cold extrusion forming enhances the compactness of threaded metal fibers, and the tensile strength of nail threads is increased by more than 30% compared to machining processes, making them less prone to slipping or breaking.
2. Durable and wear-resistant, with low downtime
The tooth surface undergoes ion nitriding and carburizing strengthening treatment, providing resistance to seizure and iron chip scratching, and slow wear due to continuous production over a long period of time. Qualified mold steel can sustain the production of hundreds of thousands of nails, while tungsten steel can achieve production in the millions.
contact us
Please contact us info@aiemachine.com +8617762388331 , if any inquiry or question.
